| Serie
imperial |
| Denominación |
Rosca |
Tuerca |
Pernos
secundarios
|
Arandela |
Fuerza
de apriete |
Torque
requerido |
Peso |
| d |
D |
T |
C |
L |
Cant. |
J |
H |
Dw |
t |
| - |
" |
mm |
mm |
mm |
mm |
- |
" |
" |
mm |
mm |
libras |
ft*lbs |
kg |
| MTSX-425-.../w |
4.1/4 |
189.2 |
83.8 |
147.3 |
118.9 |
20 |
3/4 |
5/8 |
175.3 |
9.7 |
806,400.0 |
189.0 |
12.6 |
| MTSX-450-.../w |
4.1/2 |
201.9 |
91.4 |
153.7 |
126.5 |
18 |
3/4 |
5/8 |
188.0 |
9.7 |
806,400.0 |
288.0 |
15.7 |
| MTSX-475-.../w |
4.3/4 |
208.3 |
101.6 |
170.7 |
136.7 |
20 |
3/4 |
5/8 |
200.7 |
9.7 |
907,200.0 |
288.0 |
18.3 |
| MTSX-500-.../w |
5 |
214.6 |
101.6 |
170.5 |
136.7 |
20 |
3/4 |
5/8 |
200.7 |
9.7 |
1,100,800.0 |
288.0 |
19.2 |
| MTSX-525-.../w |
5.1/4 |
227.3 |
106.7 |
175.5 |
144.8 |
18 |
3/4 |
5/8 |
213.4 |
12.7 |
1,108,800.0 |
435.0 |
22.7 |
| MTSX-550-.../w |
5.1/2 |
240.0 |
106.7 |
181.9 |
144.8 |
20 |
3/4 |
5/8 |
213.4 |
9.7 |
1,108,800.0 |
435.0 |
25.3 |
| MTSX-575-.../w |
5.3/4 |
252.7 |
127.0 |
197.4 |
168.4 |
18 |
3/4 |
5/8 |
238.8 |
9.7 |
1,209,600.0 |
623.0 |
33.5 |
| MTSX-600-.../w |
6 |
252.7 |
127.0 |
197.6 |
168.4 |
18 |
3/4 |
5/8 |
238.8 |
9.7 |
1,209,600.0 |
623.0 |
32.2 |
|
| Serie
milimétrica |
| Denominación |
Rosca |
Tuerca |
Pernos
secundarios
|
Arandela |
Fuerza
de apriete |
Torque
requerido |
Peso |
| d |
D |
T |
C |
L |
Cant. |
J |
H |
Dw |
t |
| - |
" |
mm |
mm |
mm |
mm |
- |
" |
" |
mm |
mm |
libras |
ft*lbs |
kg |
| Denominación |
Rosca |
OD |
T |
C |
L |
Cantidad |
Rosca |
Hex |
Dw |
t |
|
|
|
| MTSX-M110-…/w |
M110 |
189.0 |
76.0 |
139.0 |
108.0 |
18 |
20.0 |
17.0 |
175.0 |
10.0 |
1,064,880.0 |
189.0 |
11.8 |
| MTSX-M120-…/w |
M120 |
202.0 |
91.0 |
154.0 |
123.0 |
20 |
20.0 |
17.0 |
188.0 |
10.0 |
1,183,200.0 |
230.0 |
15.7 |
| MTSX-M140-…/w |
M140 |
240.0 |
107.0 |
185.0 |
143.0 |
24 |
24.0 |
19.0 |
213.0 |
13.0 |
1,638,000.0 |
390.0 |
26.1 |
| MTSX-M160-…/w |
M160 |
264.0 |
127.0 |
207.0 |
166.0 |
27 |
27.0 |
19.0 |
239.0 |
13.0 |
2,136,000.0 |
563.0 |
36.6 |
|
|
