| Serie
imperial |
| Denominación |
Rosca |
Tuerca |
Pernos
secundarios
|
Arandela |
Fuerza
de apriete |
Torque
requerido |
Peso |
| d |
D |
T |
C |
L |
Cant. |
J |
H |
Dw |
t |
| - |
" |
mm |
mm |
mm |
mm |
- |
" |
" |
mm |
mm |
libras |
ft*lbs |
kg |
| MTA-075-.../w |
3/4 |
50.0 |
30.0 |
34.3 |
30.0 |
4 |
1/4 |
3/16 |
44.5 |
3.3 |
20,400.0 |
14.0 |
0.4 |
| MTA-087-.../w |
7/8 |
53.1 |
30.0 |
37.5 |
30.0 |
6 |
1/4 |
3/16 |
47.8 |
3.3 |
30,600.0 |
14.0 |
0.4 |
| MTA-100-…/w |
1 |
62.7 |
38.1 |
43.4 |
38.1 |
6 |
5/16 |
1/4 |
57.2 |
4.1 |
48,600.0 |
23.0 |
0.8 |
| MTA-112-…/w |
1.1/8 |
65.8 |
38.1 |
46.6 |
38.1 |
6 |
5/16 |
1/4 |
63.5 |
4.1 |
48,600.0 |
27.0 |
0.9 |
| MTA-125-…/w |
1.1/4 |
68.6 |
38.1 |
49.8 |
38.1 |
8 |
5/16 |
1/4 |
63.5 |
4.1 |
64,800.0 |
27.0 |
0.9 |
| MTA-137-…/w |
1.3/8 |
81.3 |
45.7 |
57.3 |
45.7 |
6 |
3/8 |
5/16 |
76.2 |
5.1 |
73,800.0 |
49.0 |
1.6 |
| MTA-150-…/w |
1.1/2 |
84.3 |
45.7 |
60.5 |
45.7 |
8 |
3/8 |
5/16 |
76.2 |
5.1 |
98,400.0 |
49.0 |
1.7 |
| MTA-162-…/w |
1.5/8 |
87.6 |
45.7 |
63.6 |
45.7 |
8 |
3/8 |
5/16 |
82.6 |
5.1 |
98,400.0 |
49.0 |
1.7 |
| MTA-175-…/w |
1.3/4 |
94.0 |
55.9 |
69.1 |
55.9 |
8 |
7/16 |
3/8 |
88.9 |
6.4 |
129,600.0 |
75.0 |
2.4 |
| MTA-187-…/w |
1.7/8 |
100.8 |
58.4 |
75.6 |
58.4 |
8 |
1/2 |
7/16 |
95.3 |
6.4 |
175,200.0 |
114.0 |
2.9 |
| MTA-200-.../w |
2 |
106.7 |
58.4 |
78.7 |
58.4 |
8 |
1/2 |
7/16 |
101.6 |
6.4 |
175,200.0 |
114.0 |
3.3 |
| MTA-225-.../w |
2.1/4 |
113.0 |
58.4 |
85.1 |
58.4 |
10 |
1/2 |
7/16 |
108.0 |
6.4 |
175,200.0 |
114.0 |
3.5 |
| MTA-250-.../w |
2.1/2 |
138.4 |
74.9 |
99.1 |
74.9 |
8 |
5/8 |
9/16 |
127.0 |
8.1 |
285,600.0 |
233.0 |
7.0 |
| MTA-275-.../w |
2.3/4 |
144.8 |
74.9 |
105.4 |
74.9 |
10 |
5/8 |
9/16 |
133.4 |
8.1 |
285,600.0 |
233.0 |
7.4 |
| MTA-300-.../w |
3 |
151.1 |
74.9 |
111.8 |
74.9 |
10 |
5/8 |
9/16 |
139.7 |
8.1 |
428,400.0 |
233.0 |
7.8 |
| MTA-325-.../w |
3.1/4 |
157.5 |
74.9 |
118.1 |
74.9 |
12 |
5/8 |
9/16 |
146.1 |
8.1 |
428,400.0 |
233.0 |
8.3 |
| MTA-350-.../w |
3.1/2 |
163.8 |
74.9 |
124.5 |
74.9 |
12 |
5/8 |
9/16 |
152.4 |
8.1 |
571,200.0 |
233.0 |
8.7 |
| MTA-375-.../w |
3.3/4 |
170.2 |
74.9 |
130.8 |
74.9 |
12 |
5/8 |
9/16 |
162.6 |
8.1 |
571,200.0 |
233.0 |
9.6 |
| MTA-400-.../w |
4 |
182.9 |
74.9 |
137.2 |
74.9 |
14 |
5/8 |
9/16 |
162.6 |
8.1 |
642,600.0 |
233.0 |
10.9 |
| MTA-425-.../w |
4.1/4 |
189.2 |
92.7 |
149.2 |
92.7 |
12 |
3/4 |
5/8 |
181.6 |
9.7 |
806,400.0 |
390.0 |
13.9 |
| MTA-450-.../w |
4.1/2 |
200.7 |
92.7 |
155.6 |
92.7 |
12 |
3/4 |
5/8 |
188.0 |
9.7 |
806,400.0 |
390.0 |
15.7 |
| MTA-475-.../w |
4.3/4 |
208.3 |
92.7 |
161.9 |
92.7 |
14 |
3/4 |
5/8 |
194.3 |
9.7 |
907,200.0 |
390.0 |
16.6 |
| MTA-500-.../w |
5 |
213.4 |
92.7 |
168.3 |
92.7 |
14 |
3/4 |
5/8 |
200.7 |
9.7 |
1,100,800.0 |
390.0 |
17.4 |
| MTA-525-.../w |
5.1/4 |
218.4 |
92.7 |
174.6 |
92.7 |
14 |
3/4 |
5/8 |
207.0 |
9.7 |
1,108,800.0 |
390.0 |
17.4 |
| MTA-550-.../w |
5.1/2 |
226.1 |
92.7 |
181.0 |
92.7 |
16 |
3/4 |
5/8 |
213.4 |
9.7 |
1,108,800.0 |
390.0 |
18.3 |
| MTA-575-.../w |
5.3/4 |
233.7 |
92.7 |
187.3 |
92.7 |
16 |
3/4 |
5/8 |
219.7 |
9.7 |
1,209,600.0 |
390.0 |
19.2 |
| MTA-600-.../w |
6 |
240.0 |
92.7 |
193.7 |
92.7 |
16 |
3/4 |
5/8 |
226.1 |
9.7 |
1,209,600.0 |
390.0 |
20.0 |
|
| Serie
milimétrica |
| Denominación |
Rosca |
Tuerca |
Pernos
secundarios
|
Arandela |
Fuerza
de apriete |
Torque
requerido |
Peso |
| d |
D |
T |
C |
L |
Cant. |
J |
H |
Dw |
t |
| - |
mm |
mm |
mm |
mm |
mm |
- |
" |
" |
mm |
mm |
libras |
ft*lbs |
kg |
| MTA-M20-.../w |
M
20 |
50.0 |
30.0 |
35.0 |
30.0 |
6 |
6.0 |
5.0 |
44.0 |
3.0 |
24,300.0 |
11.0 |
0.4 |
| MTA-M24-.../w |
M
24 |
63.0 |
38.0 |
43.0 |
38.0 |
4 |
8.0 |
6.0 |
57.0 |
4.0 |
32,400.0 |
27.0 |
0.8 |
| MTA-M27-.../w |
M
27 |
66.0 |
38.0 |
46.0 |
38.0 |
6 |
8.0 |
6.0 |
64.0 |
4.0 |
48,600.0 |
27.0 |
0.9 |
| MTA-M30-.../w |
M
30 |
69.0 |
38.0 |
49.0 |
38.0 |
6 |
8.0 |
6.0 |
64.0 |
4.0 |
48,600.0 |
27.0 |
1.0 |
| MTA-M33-.../w |
M
33 |
81.0 |
46.0 |
56.0 |
46.0 |
6 |
10.0 |
8.0 |
76.0 |
5.0 |
77,400.0 |
53.0 |
1.6 |
| MTA-M36-.../w |
M
36 |
84.0 |
46.0 |
59.0 |
46.0 |
6 |
10.0 |
8.0 |
76.0 |
5.0 |
77,400.0 |
53.0 |
1.7 |
| MTA-M39-.../w |
M
39 |
88.0 |
46.0 |
62.0 |
46.0 |
8 |
10.0 |
8.0 |
83.0 |
5.0 |
103,200.0 |
53.0 |
1.8 |
| MTA-M42-.../w |
M
42 |
91.0 |
46.0 |
65.0 |
46.0 |
8 |
10.0 |
8.0 |
83.0 |
5.0 |
103,200.0 |
53.0 |
2.0 |
| MTA-M45-.../w |
M
45 |
100.0 |
58.0 |
72.0 |
58.0 |
6 |
12.0 |
10.0 |
95.0 |
6.0 |
117,900.0 |
98.0 |
3.0 |
| MTA-M48-.../w |
M
48 |
100.0 |
58.0 |
75.0 |
58.0 |
8 |
12.0 |
10.0 |
95.0 |
6.0 |
157,200.0 |
98.0 |
3.0 |
| MTA-M52-.../w |
M
52 |
104.0 |
58.0 |
79.0 |
58.0 |
8 |
12.0 |
10.0 |
102.0 |
6.0 |
157,200.0 |
98.0 |
3.1 |
| MTA-M56-.../w |
M
56 |
107.0 |
58.0 |
83.0 |
58.0 |
10 |
12.0 |
10.0 |
102.0 |
6.0 |
196,500.0 |
98.0 |
3.2 |
| MTA-M64-.../w |
M
64 |
138.0 |
75.0 |
100.0 |
75.0 |
8 |
16.0 |
14.0 |
127.0 |
8.0 |
285,600.0 |
233.0 |
7.4 |
| MTA-M72-.../w |
M
72 |
145.0 |
75.0 |
108.0 |
75.0 |
10 |
16.0 |
14.0 |
133.0 |
8.0 |
357,000.0 |
233.0 |
7.8 |
| MTA-M80-…/w |
M
80 |
151.0 |
75.0 |
116.0 |
75.0 |
12 |
16.0 |
14.0 |
140.0 |
8.0 |
428,400.0 |
233.0 |
7.8 |
| MTA-M90-.../w |
M
90 |
164.0 |
75.0 |
126.0 |
75.0 |
12 |
16.0 |
14.0 |
152.0 |
8.0 |
428,400.0 |
233.0 |
9.1 |
| MTA-M100-…/w |
M100 |
177.0 |
75.0 |
136.0 |
75.0 |
14 |
16.0 |
14.0 |
163.0 |
8.0 |
499,800.0 |
233.0 |
10.5 |
| MTA-M110-…/w |
M110 |
201.0 |
93.0 |
155.0 |
93.0 |
12 |
20.0 |
17.0 |
182.0 |
10.0 |
709,200.0 |
479.0 |
16.6 |
| MTA-M120-…/w |
M120 |
208.0 |
93.0 |
164.0 |
93.0 |
12 |
20.0 |
17.0 |
188.0 |
10.0 |
709,200.0 |
479.0 |
17.4 |
| MTA-M140-…/w |
M140 |
234.0 |
93.0 |
185.0 |
93.0 |
16 |
20.0 |
17.0 |
220.0 |
10.0 |
946,560.0 |
479.0 |
21.3 |
| MTA-M160-…/w |
M160 |
253.0 |
93.0 |
204.0 |
93.0 |
16 |
20.0 |
17.0 |
239.0 |
10.0 |
946,560.0 |
479.0 |
23.5 |
|
|
